Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	Taitien
Series	NI-10M-3500
Packaging	Box
Part Status	Active
Base Resonator	Crystal
Type	OCXO
Frequency	10 MHz
Function	–
Output	CMOS
Voltage – Supply	5V
Frequency Stability	±0.1ppb
Absolute Pull Range (APR)	–
Operating Temperature	-10°C ~ 70°C
Spread Spectrum Bandwidth	–
Current – Supply (Max)	–
Ratings	–
Mounting Type	Through Hole
Package / Case	6-DIP (1.000″, 25.40mm), 5 Leads
Size / Dimension	1.430″ L x 1.070″ W (36.32mm x 27.18mm)
Height – Seated (Max)	0.737″ (18.72mm)
Current – Supply (Disable) (Max)	–
