Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	Taitien
Series	NI-100M-2900
Packaging	Box
Part Status	Active
Base Resonator	Crystal
Type	OCXO
Frequency	100 MHz
Function	–
Output	Sine Wave
Voltage – Supply	12V
Frequency Stability	±50ppb
Absolute Pull Range (APR)	–
Operating Temperature	-40°C ~ 85°C
Current – Supply (Max)	350mA
Ratings	–
Mounting Type	Through Hole
Package / Case	6-DIP (1.000″, 25.40mm), 5 Leads
Size / Dimension	1.430″ L x 1.070″ W (36.32mm x 27.18mm)
Height – Seated (Max)	0.630″ (16.00mm)
Current – Supply (Disable) (Max)	–
