Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Standex-Meder Electronics |
| Series | KT |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 1000VAC, 1000VDC – Max |
| Coil Current | 25 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | PC Pin |
| Seal Rating | Sealed – Fully |
| Must Operate Voltage | 9 VDC |
| Must Release Voltage | 1 VDC |
| Operating Temperature | -40°C ~ 100°C |
| Contact Material | – |
| Coil Resistance | 475 Ohms |
