Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Standex-Meder Electronics |
| Series | DIP |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 250 mA |
| Switching Voltage | 175VAC, 175VDC – Max |
| Coil Current | 25 mA |
| Coil Type | Non Latching |
| Features | Diode |
| Termination Style | PC Pin |
| Seal Rating | – |
| Must Operate Voltage | 3.5 VDC |
| Must Release Voltage | 0.75 VDC |
| Operate Time | 0.7 ms |
| Release Time | 1.5 ms |
| Operating Temperature | -20°C ~ 70°C |
| Contact Material | – |
| Coil Resistance | 200 Ohms |
