Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Skyworks Solutions Inc. |
| Series | – |
| Packaging | Tube |
| Part Status | Active |
| Technology | Capacitive Coupling |
| Number of Channels | 2 |
| Voltage – Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 20kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 60ns, 60ns |
| Pulse Width Distortion (Max) | 5.6ns |
| Rise / Fall Time (Typ) | 12ns, 12ns (Max) |
| Current – Output High, Low | 2A, 4A |
| Current – Peak Output | 4A |
| Voltage – Forward (Vf) (Typ) | – |
| Voltage – Output Supply | 9.4V ~ 24V |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295″, 7.50mm Width) |
| Supplier Device Package | 16-SOIC |
| Approval Agency | CQC, CSA, UR, VDE |
| Base Product Number | SI8233 |
