Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Skyworks Solutions Inc. |
| Series | Ultra™ Si545 |
| Packaging | Strip |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | XO (Standard) |
| Frequency | 100 MHz |
| Function | Enable/Disable |
| Output | LVDS |
| Voltage – Supply | 1.8V, 2.5V, 3.3V |
| Frequency Stability | ±7ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 121mA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.276″ L x 0.197″ W (7.00mm x 5.00mm) |
| Height – Seated (Max) | 0.056″ (1.43mm) |
| Current – Supply (Disable) (Max) | 112mA |
