Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CX |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 5 V |
| Voltage Range | 4 ~ 7V |
| Frequency | 2.7kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 80dB @ 5V, 10cm |
| Current – Supply | 35mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 70°C |
| Approval Agency | – |
| Ratings | Washable |
| Ingress Protection | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.378″ Dia (9.60mm) |
| Height – Seated (Max) | 0.217″ (5.50mm) |
| Base Product Number | CX-0905 |
