| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CMT |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3.6 V |
| Voltage Range | 2.5 ~ 4.5V |
| Frequency | 3.1kHz |
| Technology | Magnetic |
| Operating Mode | – |
| Duration | – |
| Sound Pressure Level (SPL) | 90dB @ 3.6V, 10cm |
| Current – Supply | 90mA |
| Port Location | Side |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | – |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.335″ L x 0.335″ W (8.50mm x 8.50mm) |
| Height – Seated (Max) | 0.138″ (3.50mm) |
| Base Product Number | CMT-8503 |
