Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	Rubycon
Series	TLV
Packaging	Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Part Status	Active
Capacitance	1000 µF
Tolerance	±20%
Voltage – Rated	25 V
ESR (Equivalent Series Resistance)	–
Lifetime @ Temp.	5000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	AEC-Q200
Applications	Automotive
Ripple Current @ Low Frequency	660 mA @ 120 Hz
Ripple Current @ High Frequency	1.1 A @ 100 kHz
Impedance	65 mOhms
Lead Spacing	–
Size / Dimension	0.492″ Dia (12.50mm)
Height – Seated (Max)	0.551″ (14.00mm)
Surface Mount Land Size	0.512″ L x 0.512″ W (13.00mm x 13.00mm)
Mounting Type	Surface Mount
Package / Case	Radial, Can – SMD
