Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Renesas Electronics Corporation |
| Series | RA6M1 |
| Packaging | Tray |
| Part Status | Active |
| DigiKey Programmable | Not Verified |
| Core Processor | ARM® Cortex®-M4 |
| Core Size | 32-Bit |
| Speed | 120MHz |
| Connectivity | CANbus, EBI/EMI, I2C, IrDA, MMC/SD, SCI, SPI, UART/USART, USB |
| Peripherals | Capacitive Touch, Crypto – AES, DMA, LVD, POR, PWM, RSA, SHA, Temp Sensor, TRNG, WDT |
| Number of I/O | 67 |
| Program Memory Size | 512KB (512K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 8K x 8 |
| RAM Size | 256K x 8 |
| Voltage – Supply (Vcc/Vdd) | 2.7V ~ 3.6V |
| Data Converters | A/D 19x12b SAR; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 100-LFQFP (14×14) |
| Package / Case | 100-LQFP |
| Base Product Number | R7FA6M1 |
