Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Pulse Electronics |
| Series | 1608 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Diplexer |
| Frequency Bands (Low / High) | 2.4GHz ~ 2.5GHz / 5.17GHz ~ 7.125GHz |
| Low Band Attenuation (min / max dB) | 33.00dB / 43.80dB |
| High Band Attenuation (min / max dB) | 40.00dB / 50.00dB |
| Return Loss (Low Band / High Band) | 12.0dB / 10.0dB |
| Grade | – |
| Qualification | – |
| Mounting Type | Surface Mount |
| Package / Case | 0603 (1608 Metric) |
