Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | PUI Audio, Inc. |
| Series | AI |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 3 V |
| Voltage Range | 2 ~ 5V |
| Frequency | 3.5kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 100dB @ 3V, 10cm |
| Current – Supply | 9mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 80°C |
| Approval Agency | – |
| Ratings | Washable |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 1.181″ Dia (30.00mm) |
| Height – Seated (Max) | 0.780″ (19.80mm) |
