Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	Phoenix Contact
Series	REL-MR
Packaging	Bulk
Part Status	Active
Mounting Type	Socketable
Coil Voltage	24VDC
Contact Form	DPDT (2 Form C)
Contact Rating (Current)	12 A
Switching Voltage	250VAC, 250VDC – Max
Load – Max Switching	–
Coil Current	32 mA
Coil Type	Non Latching
Features	Mechanical Indicator, Test Button
Termination Style	Plug In
Seal Rating	–
Coil Insulation	–
Must Operate Voltage	19.2 VDC
Must Release Voltage	–
Operate Time	15 ms
Release Time	10 ms
Operating Temperature	-40°C ~ 70°C
Contact Material	Silver Nickel (AgNi)
Approval Agency	cULus, EAC, UR
Relay Type	General Purpose
Grade	–
Qualification	–
Coil Resistance	750 Ohms
Base Product Number	10325
