Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Panasonic Electronic Components |
| Series | EZPE |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 10 µF |
| Tolerance | ±10% |
| Voltage Rating – AC | – |
| Voltage Rating – DC | 1300V (1.3kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 10 mOhms |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | Radial – 4 Leads |
| Size / Dimension | 1.634″ L x 1.181″ W (41.50mm x 30.00mm) |
| Height – Seated (Max) | 2.028″ (51.50mm) |
| Termination | PC Pins |
| Lead Spacing | 1.476″ (37.50mm) |
| Applications | DC Link, DC Filtering |
| Ratings | – |
| Features | Low ESR |
| Base Product Number | EZP-E1 |
