Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Series | PMF |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 5µF |
| Tolerance | ±10% |
| Voltage Rating – AC | 440V |
| Voltage Rating – DC | – |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -25°C ~ 70°C |
| Polarization | – |
| Applications | Motor Run |
| Lead Spacing | – |
| Size / Dimension | 1.969″ L x 1.051″ W (50.00mm x 26.70mm) |
| Height – Seated (Max) | 1.516″ (38.50mm) |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
