Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Panasonic Electric Works |
| Series | SFN4D |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Contact Form | 6PST-4NO/2NC (4 Form A, 2 Form B) |
| Contact Rating (Current) | 8 A |
| Switching Voltage | 500VAC, 500VDC – Max |
| Features | – |
| Termination Style | PC Pin |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 6 VDC |
| Operate Time | 23 ms |
| Release Time | 6 ms |
| Operating Temperature | -25°C ~ 92°C |
| Contact Material | Silver Tin Oxide (AgSnO), Gold (Au) |
| Coil Current | 16.7 mA |
| Coil Power | 400mW |
| Coil Resistance | 1.47 kOhms |
| Base Product Number | SFN4D |
