Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Omron Automation and Safety |
| Series | G7S-E |
| Packaging | Tray |
| Part Status | Active |
| Mounting Type | Socketable, Through Hole |
| Coil Voltage | 24VDC |
| Contact Form | 6PST-3NO/3NC (3 Form A, 3 Form B) |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 250VAC, 30VDC – Max |
| Features | – |
| Termination Style | PC Pin, Plug In |
| Must Operate Voltage | 19.2 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 50 ms |
| Release Time | 50 ms |
| Operating Temperature | -25°C ~ 70°C |
| Contact Material | – |
| Coil Current | 30 mA |
| Coil Power | 800mW |
| Coil Resistance | 800 Ohms |
| Base Product Number | G7S-3A3B |
