Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Olimex LTD |
| Series | OLinuXino – Allwinner A20 |
| Packaging | Bulk |
| Part Status | Active |
| Core Processor | ARM Cortex-A7 |
| Speed | 1GHz |
| Number of Cores | 2 |
| Power (Watts) | – |
| Cooling Type | – |
| Size / Dimension | 3.307″ x 2.362″ (84.00mm x 60.00mm) |
| Form Factor | – |
| Expansion Site/Bus | GPIO, microSD, SATA, SPI, UART |
| RAM Capacity/Installed | 512MB/0GB |
| Storage Interface | eMMC, microSD, NAND – Flash, SATA |
| Video Outputs | HDMI |
| Ethernet | 100/1000 Mbps (1) |
| USB | USB Host (2), USB OTG (1) |
| Digital I/O Lines | – |
| Analog Input:Output | – |
| Watchdog Timer | No |
| Contents | HDMI Cable |
| Operating Temperature | -40°C ~ 85°C |
| Base Product Number | A20-OLINUXINO |
