Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Ole Wolff Electronics Inc |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | – |
| Frequency | 2.7kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 3V, 10cm |
| Current – Supply | – |
| Port Location | Side |
| Operating Temperature | – |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | – |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.335″ L x 0.335″ W (8.50mm x 8.50mm) |
| Height – Seated (Max) | 0.130″ (3.30mm) |
