Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Ole Wolff Electronics Inc |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 2 ~ 4V |
| Frequency | 4kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Sound Pressure Level (SPL) | 70dB @ 3V, 10cm |
| Current – Supply | 90mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.157″ L x 0.157″ W (4.00mm x 4.00mm) |
| Height – Seated (Max) | 0.079″ (2.00mm) |
