| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | NXP USA Inc. |
| Series | i.MX7D |
| Packaging | Tray |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A7, ARM® Cortex®-M4 |
| Number of Cores/Bus Width | 2 Core, 32-Bit |
| Speed | 1.0GHz |
| Co-Processors/DSP | Multimedia; NEON™ MPE |
| RAM Controllers | LPDDR2, LPDDR3, DDR3, DDR3L |
| Graphics Acceleration | No |
| Display & Interface Controllers | Keypad, LCD, MIPI |
| Ethernet | 10/100/1000Mbps (2) |
| SATA | – |
| USB | USB 2.0 + PHY (1), USB 2.0 OTG + PHY (2) |
| Voltage – I/O | 1.8V, 3.3V |
| Operating Temperature | -20°C ~ 105°C (TJ) |
| Security Features | A-HAB, ARM TZ, CAAM, CSU, SJC, SNVS |
| Mounting Type | Surface Mount |
| Package / Case | 541-LFBGA |
| Supplier Device Package | 541-MAPBGA (19×19) |
| Additional Interfaces | AC’97, CAN, eCSPI, I2C, I2S, MMC/SD/SDIO, PCIe, QSPI, SAI, UART |
| Base Product Number | MCIMX7 |
