Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Nuvoton Technology Corporation |
| Series | NUC970 |
| Packaging | Tray |
| Part Status | Active |
| Core Processor | ARM926EJ-S |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Speed | 300MHz |
| Co-Processors/DSP | – |
| RAM Controllers | DDR2, LVDDR, SDRAM |
| Graphics Acceleration | Yes |
| Display & Interface Controllers | LCD |
| Ethernet | 10/100Mbps (1) |
| SATA | – |
| USB | USB 2.0 (3) |
| Voltage – I/O | 3.3V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Security Features | AES, ECC, SHA, TRNG |
| Mounting Type | Surface Mount |
| Package / Case | 216-LQFP |
| Supplier Device Package | 216-LQFP (24×24) |
| Additional Interfaces | CANbus, DMA, eMMC/SD/SDIO, GPIO, I2C, I2S, LINbus, SPI, UART/USART |
