Açıklama

ÖZELLİK	AÇIKLAMA
Mfr	Nichicon
Series	UPW
Packaging	Bulk
Part Status	Not For New Designs
Capacitance	1000 µF
Tolerance	±20%
Voltage – Rated	100 V
ESR (Equivalent Series Resistance)	–
Lifetime @ Temp.	8000 Hrs @ 105°C
Operating Temperature	-55°C ~ 105°C
Polarization	Polar
Ratings	AEC-Q200
Applications	General Purpose
Ripple Current @ Low Frequency	1.14 A @ 120 Hz
Ripple Current @ High Frequency	1.52 A @ 100 kHz
Impedance	47 mOhms
Lead Spacing	0.295″ (7.50mm)
Size / Dimension	0.709″ Dia (18.00mm)
Height – Seated (Max)	1.575″ (40.00mm)
Surface Mount Land Size	–
Mounting Type	Through Hole
Package / Case	Radial, Can
