Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Nichicon |
| Series | QXL |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 0.1 µF |
| Tolerance | ±10% |
| Voltage Rating – AC | 250V |
| Voltage Rating – DC | – |
| Dielectric Material | Polyester, Metallized |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.728″ L x 0.252″ W (18.50mm x 6.40mm) |
| Height – Seated (Max) | 0.598″ (15.20mm) |
| Termination | PC Pins |
| Lead Spacing | 0.591″ (15.00mm) |
| Applications | High Frequency, Switching |
| Ratings | – |
| Features | – |
