Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Nichicon |
| Series | PPA |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 10000 pF |
| Tolerance | ±10% |
| Voltage Rating – AC | 750V |
| Voltage Rating – DC | 3000V (3kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 54.5 mOhms |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | Axial |
| Size / Dimension | 0.394″ Dia x 1.260″ L (10.00mm x 32.00mm) |
| Height – Seated (Max) | – |
| Termination | PC Pins |
| Lead Spacing | – |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Ratings | – |
| Features | – |
