Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Murata Electronics |
| Series | RCE |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Active |
| Capacitance | 10 µF |
| Tolerance | ±20% |
| Voltage – Rated | 50V |
| Temperature Coefficient | X7R |
| Operating Temperature | -55°C ~ 125°C |
| Features | – |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.217″ L x 0.157″ W (5.50mm x 4.00mm) |
| Height – Seated (Max) | 0.295″ (7.50mm) |
| Thickness (Max) | – |
| Lead Spacing | 0.197″ (5.00mm) |
| Lead Style | Formed Leads |
| Base Product Number | RCER71H |
