Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Murata Electronics |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Diplexer |
| Frequency Bands (Low / High) | 617MHz ~ 960MHz, 1.427GHz ~ 1.511GHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.496GHz, 2.496GHz ~ 2.69GHz / 3.3GHz ~ 3.4GHz, 3.4GHz ~ 3.8GHz, 5.15GHz ~ 5.925GHz |
| Low Band Attenuation (min / max dB) | 16.30dB / – |
| High Band Attenuation (min / max dB) | 14.00dB / – |
| Return Loss (Low Band / High Band) | – |
| Grade | – |
| Qualification | – |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric), 8 PC Pad |
