Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Mixtile Limited |
| Series | – |
| Packaging | Box |
| Part Status | Active |
| Core Processor | Rockchip RK3568, Quad-Core-A55 |
| Speed | 2GHz |
| Number of Cores | 4 |
| Power (Watts) | 10W |
| Cooling Type | Heat Sink |
| Size / Dimension | 3.937″ x 5.512″ (100.00mm x 140.00mm) |
| Form Factor | Pico-ITX |
| Expansion Site/Bus | ADC, CAN, I2C, RS-485, SPDIF, UART |
| RAM Capacity/Installed | 2GB |
| Storage Interface | eMMC 5.1 |
| Video Outputs | HDMI 2.0 |
| Ethernet | GbE (1) |
| USB | USB 3.0 (3) |
| Digital I/O Lines | 4 |
| Analog Input:Output | 4 |
| Watchdog Timer | Yes |
| Contents | – |
| Operating Temperature | 0°C ~ 80°C |
| Base Product Number | SBC-EDGE2 |
