Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Microchip Technology |
| Series | – |
| Packaging | Tray |
| Part Status | Active |
| Core Processor | RV64GC |
| Number of Cores/Bus Width | 4 Core, 64-Bit |
| Speed | 625MHz |
| Co-Processors/DSP | RV64IMAC |
| RAM Controllers | DDR4, LPDDR4 |
| Graphics Acceleration | No |
| Display & Interface Controllers | HDMI, MIPI-CSI2 |
| Ethernet | 10/100/1000Mbps (2) |
| SATA | – |
| USB | USB 2.0 OTG (1) |
| Voltage – I/O | 1.2V, 1.5V, 1.8V, 2.5V, 3.3V |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Grade | – |
| Qualification | – |
| Security Features | AES, Boot Security, Cryptography, SHA, TRNG |
| Mounting Type | Surface Mount |
| Package / Case | 325-TFBGA |
| Supplier Device Package | 325-CSPBGA (11×11) |
| Additional Interfaces | CANbus, DMA, GPIO, I2C, MMC/SD, PCIe, QSPI, SPI, UART/USART |
