Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Mallory Sonalert Products Inc. |
| Series | SC |
| Packaging | Bulk |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage Range | 10 ~ 48V |
| Frequency | 2.9kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 68dB @ 10V, 61cm |
| Current – Supply | 4 ~ 18mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 65°C |
| Approval Agency | cUL, UL |
| Ratings | – |
| Mounting Type | Panel Mount |
| Termination | Screw Terminal, Quick Connect Tab – 0.250″ (6.35mm) |
| Size / Dimension | 1.692″ Dia (42.98mm) |
| Height – Seated (Max) | 1.330″ (33.77mm) |
