Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Mallory Sonalert Products Inc. |
| Series | PT |
| Packaging | Bulk |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage – Rated | 5 V |
| Voltage Range | 1 ~ 25V |
| Frequency | 4kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 5V, 10cm |
| Current – Supply | 1.5mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 100°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.669″ Dia (17.00mm) |
| Height – Seated (Max) | 0.370″ (9.40mm) |
