Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Mallory Sonalert Products Inc. |
| Series | PB |
| Packaging | Bulk |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 3.3 V |
| Voltage Range | 2 ~ 5V |
| Frequency | 2.7kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 3.3V, 10cm |
| Current – Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.354″ Dia (9.00mm) |
| Height – Seated (Max) | 0.224″ (5.70mm) |
