Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Mallory Sonalert Products Inc. |
| Series | ASI |
| Packaging | Tube |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 5 V |
| Voltage Range | 4 ~ 7V |
| Frequency | 2.4kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 90dB @ 5V, 10cm |
| Current – Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 70°C |
| Approval Agency | – |
| Ratings | Washable |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.496″ L x 0.496″ W (12.60mm x 12.60mm) |
| Height – Seated (Max) | 0.402″ (10.20mm) |
