Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | KEMET |
| Series | EM1 |
| Packaging | Tube |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Current | 53.3 mA |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (DM) (1 Form U) |
| Contact Rating (Current) | 54 A |
| Switching Voltage | 16VDC – Max |
| Must Operate Voltage | 6.5 VDC |
| Must Release Voltage | 0.9 VDC |
| Operate Time | 6 ms |
| Release Time | 1 ms |
| Features | Sealed – Fully |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Operating Temperature | -40°C ~ 125°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Coil Power | 640mW |
| Coil Resistance | 225 Ohms |
