ÖZELLİK	AÇIKLAMA
Manufacturer	KEMET
Series	EE2
Packaging	Tape & Reel (TR), Cut Tape (CT), Digi-Reel®
Part Status	Active
Mounting Type	Surface Mount
Coil Voltage	5VDC
Contact Form	DPDT (2 Form C)
Contact Rating (Current)	2 A
Switching Voltage	250VAC, 220VDC – Max
Load – Max Switching	500VA, 440W
Coil Current	28 mA
Coil Type	Latching, Dual Coil
Features	–
Termination Style	Gull Wing
Seal Rating	–
Coil Insulation	–
Must Operate Voltage	3.75 VDC
Must Release Voltage	–
Operate Time	2 ms
Release Time	1 ms
Operating Temperature	-40°C ~ 85°C
Contact Material	Silver Alloy, Gold Alloy
Approval Agency	CSA, TUV, UL
Relay Type	General Purpose
Grade	–
Qualification	–
Coil Resistance	178 Ohms
Base Product Number	EE2-5T
