Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | KEMET |
| Series | EE2 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Coil Voltage | 3VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 250VAC, 220VDC – Max |
| Load – Max Switching | 500VA, 440W |
| Coil Current | 46.7 mA |
| Coil Type | Latching, Dual Coil |
| Features | – |
| Termination Style | Gull Wing |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | 2.25 VDC |
| Must Release Voltage | – |
| Operate Time | 2 ms |
| Release Time | 1 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Alloy, Gold Alloy |
| Approval Agency | CSA, TUV, UL |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 64.3 Ohms |
| Base Product Number | EE2-3T |
