Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | iWave Global |
| Series | i.MX 8XLite |
| Packaging | Bulk |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A35, ARM® Cortex®-M4 |
| Speed | – |
| Number of Cores | 2/1 |
| Power (Watts) | 12.5W |
| Cooling Type | Heat Sink, Heat Spreader |
| Size / Dimension | 1.181″ x 1.181″ (30.00mm x 30.00mm) |
| Form Factor | OSM |
| Expansion Site/Bus | CAN, GPIO, I2C, I2S, JTAG, PCIe, SPI, UART |
| RAM Capacity/Installed | 2GB |
| Storage Interface | eMMC |
| Video Outputs | – |
| Ethernet | 1GbE |
| USB | USB 2.0 (1), USB 2.0 OTG (1) |
| Digital I/O Lines | 17 |
| Analog Input:Output | – |
| Watchdog Timer | Yes |
| Contents | – |
| Operating Temperature | -40°C ~ 105°C |
