Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Infineon Technologies |
| Series | FM4 S6E2H4 |
| Packaging | Tray |
| Part Status | Active |
| DigiKey Programmable | Not Verified |
| Core Processor | ARM® Cortex®-M4F |
| Core Size | 32-Bit |
| Speed | 160MHz |
| Connectivity | CANbus, CSIO, EBI/EMI, I2C, LINbus, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Number of I/O | 100 |
| Program Memory Size | 544KB (544K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | – |
| RAM Size | 64K x 8 |
| Voltage – Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Data Converters | A/D 24x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 120-LQFP (16×16) |
| Package / Case | 120-LQFP |
| Base Product Number | S6E2H46 |
