Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Infineon Technologies |
| Series | PVT, HEXFET® |
| Packaging | Tube |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Circuit | SPST-NO (1 Form A) |
| Output Type | AC, DC |
| Voltage – Input | 1.2VDC |
| Voltage – Load | 0 V ~ 150 V |
| Load Current | 550 mA |
| On-State Resistance (Max) | 750 mOhms |
| Termination Style | Gull Wing |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 6-SMD (0.300″, 7.62mm) |
| Supplier Device Package | 6-SMT |
| Approval Agency | UL |
| Grade | – |
| Qualification | – |
| Base Product Number | PVT212 |
