Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Gateworks Corporation |
| Series | – |
| Packaging | Bulk |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A53, i.MX8M Plus Quad |
| Speed | 1.6GHz |
| Number of Cores | 4 |
| Power (Watts) | 3.9W |
| Cooling Type | – |
| Size / Dimension | 3.900″ x 2.750″ (99.06mm x 69.85mm) |
| Form Factor | – |
| Expansion Site/Bus | I2C, I2S, microSD, Mini-PCIe, MIPI-CSI, MIPI-DSI, RS-232, RS-485, SIM, SPI, TTL |
| RAM Capacity/Installed | 4GB/0GB |
| Storage Interface | eMMC, M.2, microSD, Mini PCIe, SPI |
| Video Outputs | MIPI CSI, MIPI DSI, TTL |
| Ethernet | GbE (2) |
| USB | USB 2.0 (1) |
| Digital I/O Lines | – |
| Analog Input:Output | – |
| Watchdog Timer | Yes |
| Contents | – |
| Operating Temperature | -40°C ~ 85°C |
