Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Finder Relays, Inc. |
| Series | 20 |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | DIN Rail |
| Coil Voltage | 12VDC |
| Contact Form | DPST-NO (2 Form A) |
| Contact Rating (Current) | 16 A |
| Switching Voltage | 400VAC – Max |
| Load – Max Switching | 6400VA |
| Coil Current | 440 mA |
| Coil Type | Latching, Single Coil |
| Features | Mechanical Indicator, Test Button |
| Termination Style | Screw Terminal |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | 10.8 VDC |
| Must Release Voltage | – |
| Operating Temperature | -40°C ~ 40°C |
| Contact Material | Silver Nickel (AgNi) |
| Approval Agency | CE, cULus, EAC, RINA, UKCA |
| Relay Type | Impulse |
| Coil Resistance | 27 Ohms |
| Base Product Number | 20.22.9 |
