| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Ezurio |
| Series | N8MP |
| Packaging | Bulk |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A53, ARM® Cortex®-M7 |
| Speed | 800MHz, 1.8GHz |
| Number of Cores | 1/4 |
| Power (Watts) | – |
| Cooling Type | – |
| Size / Dimension | 3.228″ x 1.969″ (81.99mm x 50.01mm) |
| Form Factor | SMARC2.1.1 |
| Expansion Site/Bus | Audio, CAN, GPIO, I2C, SPI, SDIO, UART, Wi-Fi/Bluetooth |
| RAM Capacity/Installed | 8GB/0GB |
| Storage Interface | eMMC |
| Video Outputs | HDMI, LVDS, MIPI CSI, MIPI-DSI |
| Ethernet | – |
| USB | USB 2.0 (4), USB 3.0 (2) |
| Digital I/O Lines | – |
| Analog Input:Output | – |
| Watchdog Timer | No |
| Contents | – |
| Operating Temperature | -40°C ~ 85°C |
