Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | EPCOS – TDK Electronics |
| Series | HVC25 |
| Packaging | Box |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 300 A |
| Switching Voltage | 1000VDC – Max |
| Features | Sealed – Hermetically |
| Termination Style | Stud, Wire Leads |
| Operating Temperature | -40°C ~ 85°C |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2 VDC |
| Contact Material | Copper Alloy |
| Operate Time | 35 ms |
| Release Time | 15 ms |
| Coil Current | 250 mA |
| Coil Power | 6W |
| Coil Resistance | 96Ohms |
