Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | EPCOS – TDK Electronics |
| Series | B43504 |
| Packaging | Bulk |
| Part Status | Not For New Designs |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage – Rated | 450 V |
| ESR (Equivalent Series Resistance) | 1.35Ohm @ 100Hz |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | – |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 640 mA @ 100 Hz |
| Impedance | 1.6 Ohms |
| Lead Spacing | 0.394″ (10.00mm) |
| Size / Dimension | 0.866″ Dia (22.00mm) |
| Height – Seated (Max) | 1.457″ (37.00mm) |
| Surface Mount Land Size | – |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can – Snap-In |
