ÖZELLİK	AÇIKLAMA
Manufacturer	ECS Inc.
Series	ECS-P85X
Packaging	Tube
Part Status	Active
Base Resonator	Crystal
Type	XO (Standard)
Programmable Type	Programmed by Digi-Key (Enter your frequency in Web Order Notes)
Available Frequency Range	1 MHz ~ 150 MHz
Function	Enable/Disable
Output	HCMOS
Voltage – Supply	5V
Frequency Stability	–
Frequency Stability (Total)	±50ppm
Operating Temperature	0°C ~ 70°C
Spread Spectrum Bandwidth	–
Current – Supply (Max)	45mA
Ratings	–
Mounting Type	Through Hole
Package / Case	8-DIP, 4 Leads (Half Size, Metal Can)
Size / Dimension	0.520″ L x 0.520″ W (13.20mm x 13.20mm)
Height – Seated (Max)	0.213″ (5.40mm)
