Açıklama

ÖZELLİK	AÇIKLAMA
Manufacturer	ECS Inc.
Series	ECS-P145
Packaging	Tube
Part Status	Active
Base Resonator	Crystal
Type	XO (Standard)
Programmable Type	Programmed by Digi-Key (Enter your frequency in Web Order Notes)
Available Frequency Range	1 MHz ~ 150 MHz
Function	Enable/Disable
Output	HCMOS
Voltage – Supply	5V
Frequency Stability	–
Frequency Stability (Total)	±50ppm
Operating Temperature	0°C ~ 70°C
Spread Spectrum Bandwidth	–
Current – Supply (Max)	45mA
Ratings	–
Mounting Type	Through Hole
Package / Case	14-DIP, 4 Leads (Full Size, Metal Can)
Size / Dimension	0.815″ L x 0.508″ W (20.70mm x 12.90mm)
Height – Seated (Max)	0.197″ (5.00mm)
