Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Eaton – Electronics Division |
| Series | HV |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 1 F |
| Tolerance | -10%, +30% |
| Voltage – Rated | 2.7 V |
| ESR (Equivalent Series Resistance) | 200mOhm @ 100Hz |
| Lifetime @ Temp. | 1000 Hrs @ 65°C |
| Grade | – |
| Qualification | – |
| Termination | PC Pins |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Lead Spacing | 0.138″ (3.50mm) |
| Size / Dimension | 0.315″ Dia (8.00mm) |
| Height – Seated (Max) | 0.532″ (13.50mm) |
| Operating Temperature | -40°C ~ 65°C |
