Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | CTS Resistor Products |
| Series | S4x |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Circuit Type | Isolated |
| Resistance (Ohms) | 390k |
| Tolerance | ±5% |
| Number of Resistors | 2 |
| Resistor Matching Ratio | – |
| Resistor-Ratio-Drift | – |
| Number of Pins | 4 |
| Power Per Element | 63mW |
| Temperature Coefficient | ±200ppm/°C |
| Operating Temperature | -55°C ~ 125°C |
| Grade | – |
| Qualification | – |
| Applications | DDR SDRAM, DRAM, MDDR |
| Mounting Type | Surface Mount |
| Package / Case | 0404 (1010 Metric), Convex |
| Supplier Device Package | 0404 |
| Size / Dimension | 0.039″ L x 0.039″ W (1.00mm x 1.00mm) |
| Height – Seated (Max) | 0.016″ (0.40mm) |
