Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Coto Technology |
| Series | B41 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Last Time Buy |
| Coil Type | Non Latching |
| Coil Current | 31.3 mA |
| Coil Voltage | 5VDC |
| Contact Form | SPST-NO (1 Form A) x 4 |
| Contact Rating (Current) | 250 mA |
| Switching Voltage | 125VAC, 125VDC – Max |
| Must Operate Voltage | 3.8 VDC |
| Must Release Voltage | 0.4 VDC |
| Operate Time | 0.1 ms |
| Release Time | 0.03 ms |
| Features | – |
| Mounting Type | Surface Mount |
| Termination Style | BGA |
| Operating Temperature | -20°C ~ 85°C |
| Contact Material | – |
| Coil Power | – |
| Coil Resistance | 160 Ohms |
