Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Coto Technology |
| Series | 9900 |
| Packaging | Tube |
| Part Status | Not For New Designs |
| Mounting Type | Surface Mount |
| Coil Voltage | 5VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 250 mA |
| Switching Voltage | 100VAC, 100VDC – Max |
| Coil Current | 33.3 mA |
| Coil Type | Non Latching |
| Features | EMI Shielded |
| Termination Style | J Lead |
| Seal Rating | – |
| Must Operate Voltage | 3.8 VDC |
| Must Release Voltage | 0.4 VDC |
| Operate Time | 0.25 ms |
| Release Time | 0.05 ms |
| Operating Temperature | -20°C ~ 85°C |
| Contact Material | – |
| Coil Resistance | 150 Ohms |
| Base Product Number | 9901-0 |
